70mm
≤150kg
60m/min
Carbon steel plate, stainless steel plate, galvanized plate, aluminum alloy, etc
Heating, chemical, food, machinery, textile, printing and dyeing, feed, medicine, building materials, etc
Can easily handle complex designs and geometric shapes
Chuck has automatic center adjustment function, which can quickly center the clamping
Standard pneumatic gradient concave wheel auxiliary support can prevent the weight of the processed material from sagging and the pipe deformation, and improve cutting accuracy
Can cut pipes of different materials and shapes, eliminating the need for multiple machines and saving costs
Model: YL6012MQ YL6016MQ
Eliminating welding stress through high-temperature annealing and natural aging
High intensity workbench, easy to disassemble and replace, no hindrance to production
Real time dynamic feedback servo drive, precision gear transmission
Advanced control system for intuitive adjustment of laser power
| Model | 6012MQ | 6016MQ | |||
| Cutting profile size | Equipment length ≤ 6500mm, ф 10mm ≤ circular tube diameter≤ ф 120mm. 10mm ≤ rectangular tube and square tube Pipediagonal ≤ 120mm | Equipment length ≤ 6500mm, Ф 10mm ≤ circular tube diameter≤ ф 160mm. 10mm ≤ rectangular tube and square tube Pipediagonal s 160mm | |||
| Weight of a single pipe | ≤150kg | ≤150kg | |||
| X-axis stroke | 300mm | 300mm | |||
| Z-axis stroke | 300mm | 300mm | |||
| Tail material (clamping method affects tail material length) | 70 | 70 | |||
| X/Y/Z axis positioning accuracy | ±0.04mm/m | ±0.04mm/m | |||
| X/Y/Z axis repeat positioning accuracy | ±0.03mm/m | ±0.03mm/m | |||
| Maximum acceleration of the rear chuck during travel | 1.5G | 1.5G | |||
| Maximum walking speed of the rear chuck | 60m/min | 60m/min | |||
| Maximum speed of rear chuck | 200r/min | 120r/min |
* The above data is for reference only. Please refer to the actual product and product manual for specific information. Unless otherwise specified, the interpretation rights of the data involved in this website belong to YONIK Laser.
