90mm
≤800kg
85m/min
Carbon steel plate, stainless steel plate, galvanized plate, aluminum alloy, etc
Heating, chemical, food, machinery, textile, printing and dyeing, feed, medicine, building materials, etc
Can easily handle complex designs and geometric shapes
Chuck has automatic center adjustment function, which can quickly center the clamping
High cost performance, can cut up to 6.5m, tail material 90mm
Can cut pipes of different materials and shapes, eliminating the need for multiple machines and saving costs
Model: YL6016JY YL6024JY YL6035JY
Eliminating welding stress through high-temperature annealing and natural aging
High intensity workbench, easy to disassemble and replace, no hindrance to production
Real time dynamic feedback servo drive, precision gear transmission
Advanced control system for intuitive adjustment of laser power
| Model | 6016JY | 6024JY | 6035JY | ||
| Cutting profile size | Equipment length ≤ 6500mm, 中 15mmS circular tube diameter ≤ φ 160mm.15mm ≤ rectangular tube and square tubePipe diagonal ≤ 160mm | Equipment length ≤ 6500mm, 中 15mmS circular tube diameter ≤ Φ 240mm.15mm ≤ rectangular tube and square tubePipe diagonal ≤ 240mm | Equipment length ≤ 6500mm, 中 15mmS circular tube diameter s φ 350mm.15mm ≤ rectangular tube and square tubePipe diagonal ≤ 350mm | ||
| Weight of a single pipe | ≤150kg | ≤300kg | ≤800kg | ||
| X-axis stroke | 300mm | 300mm | 400mm | ||
| Z-axis stroke | 300mm | 300mm | 400mm | ||
| Tail material (clamping method affects tail material length) | 90mm | 100mm | 150mm | ||
| X/Y/Z axis positioning accuracy | ±0.04mm/m | ±0.04mm/m | ±0.04mm/m | ||
| X/Y/Z axis repeat positioning accuracy | ±0.03mm/m | ±0.03mm/m | ±0.03mm/m | ||
| Maximum acceleration of the rear chuck during travel | 1.5G | 1.5G | 1.5G | ||
| Maximum walking speed of the rear chuck | 85m/min | 85m/min | 85m/min | ||
| Maximum speed of rear chuck | 120r/min | 120r/min | 120r/min |
* The above data is for reference only. Please refer to the actual product and product manual for specific information. Unless otherwise specified, the interpretation rights of the data involved in this website belong to YONIK Laser.
